如何在Magento 2中创建自定义运输方式

redmaomail 2024-07-24 18:16 阅读数 59 #Magento

Magento 2已经有一些内置的运输方式。但在某些情况下，我们可能想在Magento 2中创建自己的运输方式。这不是一个困难的过程。我们可以非常轻松地在Magento 2中创建自定义运输方式。这篇博客可以帮助您在短时间内创建自己的自定义运输方式。

创建自定义运输方法的步骤：

创建一个新模块
创建配置文件
定义运输模型
创建运输模型
模块安装

创建一个新模块：

在下面的文件路径中创建一个“registration.php”文件来注册我们的新模块，

文件路径：<Magento_2_Root> /app/code/Alwayly/CustomShipping/registration.php

<?php
\Magento\Framework\Component\ComponentRegistrar::register(
    \Magento\Framework\Component\ComponentRegistrar::MODULE,
    'Alwayly_CustomShipping',
    __DIR__
);

接下来，在下面的文件路径中创建一个“module.xml”文件来定义模块，

文件路径：<Magento_2_Root> /app/code/Alwayly/CustomShipping/etc/module.xml

<?xml version="1.0"?>
<config xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="urn:magento:framework:Module/etc/module.xsd">
    <module name="Alwayly_CustomShipping" setup_version="1.0.0">
    </module>
</config>

创建配置文件：

在Magento 2中，每个运输方式都应该在管理面板中有配置选项。我们可以通过system.xml文件为我们的运输方式创建配置选项。

文件路径：<Magento_2_Root> /app/code/Alwayly/CustomShipping/etc/adminhtml/system.xml

<?xml version="1.0"?>
<config xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="urn:magento:module:Magento_Config:etc/system_file.xsd">
    <system>
        <section id="carriers" translate="label" type="text" sortOrder="320" showInDefault="1" showInWebsite="1" showInStore="1">
            <group id="customshipping" translate="label" type="text" sortOrder="10" showInDefault="1" showInWebsite="1" showInStore="1">
                <label>Custom Shipping Method</label>
                <field id="active" translate="label" type="select" sortOrder="1" showInDefault="1" showInWebsite="1" showInStore="0" canRestore="1">
                    <label>Enabled</label>
                    <source_model>Magento\Config\Model\Config\Source\Yesno</source_model>
                </field>
                <field id="price" translate="label" type="text" sortOrder="4" showInDefault="1" showInWebsite="1" showInStore="0">
                    <label>Shipping Cost</label>
                    <validate>validate-number validate-zero-or-greater</validate>
                </field>
                <field id="name" translate="label" type="text" sortOrder="3" showInDefault="1" showInWebsite="1" showInStore="1" canRestore="1">
                    <label>Method Name</label>
                </field>
                <field id="sort_order" translate="label" type="text" sortOrder="100" showInDefault="1" showInWebsite="1" showInStore="0">
                    <label>Sort Order</label>
                </field>
                <field id="title" translate="label" type="text" sortOrder="2" showInDefault="1" showInWebsite="1" showInStore="1" canRestore="1">
                    <label>Title</label>
                </field>
                <field id="sallowspecific" translate="label" type="select" sortOrder="90" showInDefault="1" showInWebsite="1" showInStore="0" canRestore="1">
                    <label>Ship to Applicable Countries</label>
                    <frontend_class>shipping-applicable-country</frontend_class>
                    <source_model>Magento\Shipping\Model\Config\Source\Allspecificcountries</source_model>
                </field>
                <field id="specificcountry" translate="label" type="multiselect" sortOrder="91" showInDefault="1" showInWebsite="1" showInStore="0">
                    <label>Ship to Specific Countries</label>
                    <source_model>Magento\Directory\Model\Config\Source\Country</source_model>
                    <can_be_empty>1</can_be_empty>
                </field>
                <field id="showmethod" translate="label" type="select" sortOrder="92" showInDefault="1" showInWebsite="1" showInStore="0">
                    <label>Show Method if Not Applicable</label>
                    <source_model>Magento\Config\Model\Config\Source\Yesno</source_model>
                    <frontend_class>shipping-skip-hide</frontend_class>
                </field>
                <field id="specificerrmsg" translate="label" type="textarea" sortOrder="80" showInDefault="1" showInWebsite="1" showInStore="1" canRestore="1">
                    <label>Displayed Error Message</label>
                </field>
            </group>
        </section>
    </system>
</config>

定义运输模型：

现在在下面的路径中创建一个“config.xml”文件，并为我们的自定义运输方式设置默认配置，

文件路径：<Magento_2_Root> /app/code/Alwayly/CustomShipping/etc/config.xml

<?xml version="1.0"?>
<config xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="urn:magento:module:Magento_Store:etc/config.xsd">
    <default>
        <carriers>
            <customshipping>
                <active>0</active>
                <sallowspecific>0</sallowspecific>
                <price>0</price>
                <model>Alwayly\CustomShipping\Model\Carrier\Customshipping</model>
                <name>Custom Shipping</name>
                <title>Custom Shipping</title>
                <specificerrmsg>This shipping method is not available. To use this shipping method, please contact us.</specificerrmsg>
            </customshipping>
        </carriers>
    </default>
</config>

这里，<default>是父节点，其子节点是<carriers>，<customshipping>是我们的运输方式代码。<model>是重要的一个，在这个<model>标签中，我们应该定义我们的运输模型类。

创建运输模型：

在“config.xml”上定义运输模型后，我们需要在下面的文件路径中创建运输模型类“Customshipping.php”，

文件路径：<Magento_2_Root> /app/code/Alwayly/CustomShipping/Model/Carrier/Customshipping.php

<?php
namespace Alwayly\CustomShipping\Model\Carrier;

use Magento\Framework\App\Config\ScopeConfigInterface;
use Magento\Framework\DataObject;
use Magento\Shipping\Model\Carrier\AbstractCarrier;
use Magento\Shipping\Model\Carrier\CarrierInterface;
use Magento\Shipping\Model\Config;
use Magento\Shipping\Model\Rate\ResultFactory;
use Magento\Store\Model\ScopeInterface;
use Magento\Quote\Model\Quote\Address\RateResult\ErrorFactory;
use Magento\Quote\Model\Quote\Address\RateResult\Method;
use Magento\Quote\Model\Quote\Address\RateResult\MethodFactory;
use Magento\Quote\Model\Quote\Address\RateRequest;
use Psr\Log\LoggerInterface;

class Customshipping extends AbstractCarrier implements CarrierInterface
{

    /**
     * @var string
     */
    protected $_code = 'customshipping';

    /**
     * @var bool
     */
    protected $_isFixed = true;

    /**
     * @var ResultFactory
     */
    protected $_rateResultFactory;

    /**
     * @var MethodFactory
     */
    protected $_rateMethodFactory;

    /**
     * @param ScopeConfigInterface $scopeConfig
     * @param ErrorFactory $rateErrorFactory
     * @param LoggerInterface $logger
     * @param ResultFactory $rateResultFactory
     * @param MethodFactory $rateMethodFactory
     * @param array $data
     */
    public function __construct(
        ScopeConfigInterface $scopeConfig,
        ErrorFactory $rateErrorFactory,
        LoggerInterface $logger,
        ResultFactory $rateResultFactory,
        MethodFactory $rateMethodFactory,
        array $data = []
    ) {
        $this->_rateResultFactory = $rateResultFactory;
        $this->_rateMethodFactory = $rateMethodFactory;
        parent::__construct($scopeConfig, $rateErrorFactory, $logger, $data);
    }

    /**
     * @return array
     * @api
     */
    public function getAllowedMethods()
    {
        return [$this->getCarrierCode() => __($this->getConfigData('name'))];
    }

    /**
     * @SuppressWarnings(PHPMD.UnusedFormalParameter)
     * @param RateRequest $request
     * @return DataObject|bool|null
     * @api
     */
    public function collectRates(RateRequest $request)
    {
        /**
         * Make sure that shipping method is enabled
         */
        if (!$this->isActive()) {
            return false;
        }

        /** @var \Magento\Shipping\Model\Rate\Result $result */
        $result = $this->_rateResultFactory->create();
        $shippingPrice = $this->getConfigData('price');
        $method = $this->_rateMethodFactory->create();

        /**
         * Set carrier's method data
         */
        $method->setCarrier($this->getCarrierCode());
        $method->setCarrierTitle($this->getConfigData('title'));

        /**
         * Displayed as shipping method under Carrier
         */
        $method->setMethod($this->getCarrierCode());
        $method->setMethodTitle($this->getConfigData('name'));
        $method->setPrice($shippingPrice);
        $method->setCost($shippingPrice);
        $result->append($method);
        return $result;
    }
}

注意：

在Magento 2中，每个运输类都应继承\Magento\Shipping\Model\Carrier\AbstractCarrier并实现\Magento\Shipping\Model\Carrier\CarrierInterface类。
$ _code的值应与system.xml中的group id相同。
抽象类和接口需要两个函数getAllowedMethods和collectRates。
在函数collectRates中，我们必须为自定义运费计算实现所有逻辑。
